Trumbosound 12-Inch 1000W Dual Ohm Professional LF Speaker | Deep Bass Audio

Name: Trumbosound 12-Inch 1000W Dual Ohm Professional LF Speaker | Deep Bass Audio
Brand: Guangzhou Huiyin Audio Co., Ltd.
SKU: HYW-1286-001
Price: 38.8 USD
Availability: InStock

The 12-inch dual-ohm best low frequency speaker for deep bass for home from Trumbosound brings unparalleled shocking power to your sound. This built-in 200*95*20 ferrite LF speaker is designed for outdoor sound, with a peak power of 1000 watts and an AES power of 500 watts. The sound is deep and shocking, making it the best partner for outdoor line array sound systems.

0.0 (0 Reviews)

0 Sold

$38.80

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

Product details
Company profile

Bring you a deep and shocking auditory experience

Deep and powerful low-frequency output brings you a shocking listening experience.
High power handling capacity, no sound distortion or breakage.
Accurate frequency response makes the sound clearer and more accurate.
Good acoustic design makes the sound purer and smoother.

Material advantages

Lightweight
High strength and high rigidity
Good fatigue resistance
Low damping
Good stability

Parmeter

Model	HYW-1286-001
Nominal diameter	12 inch
DC Resistance	5.7Ω
BL Factor	21.62
Effective Moving Mass	77.95
Total Factor(QTS)	0.21
Electrical Factor(QMS)	7.00
Mechanical Factor(QES)	0.21
Compliance(CMS)	0.20
Equivalent Cas Air Load(VAS)	82.58
Resonance Frequency(FS)	40.26
Effettive Pistom Area(SD)	0.05
η(Eta Zero)	2.36

General Specificatons

Nominal Diameter	12 inch
Nominal Impedance	8Ω
AES power Handling AES	500W
Continuous program power	1000W
Sensitivity 1w/1m	98dB
Frequency Range	40HZ-2KHZ
Voice Coil Diameter	86mm
Winding Material	PISV/ Internal and external wet winding
Former Material	GBF
Winding Depth	17.5mm
Xmax	12mm
surround material	Paper cone cloth edge
surround Design	Type M
Magnet	200X95X20 Ferrite

Mounting&Shipping Information

Overall Diameter	317mm
Bolt circle Diameter	297.8-8-Ф7
Baffle Cutout Diameter	282mm
Depth	140mm
Net Weight净	8KG
Shipping Weight	10KG
Shipping Box(Single)	320×320×145mm

Features

Good heat dissipation, high coercivity and magnetic stability
High temperature resistance, high precision, good practicality and preservation
High sensitivity makes it easier to drive, stable and safe performance
Strong sound expression, more realistic listening experience
Carbon fiber fabric edge has strong high temperature resistance and corrosion resistance

Application

Outdoor weddings
Mobile perfomance stage
Line array system installation

Our advantage

OEM/ODM:Professional speaker audio manufacturer, focusing on the manufacture and sale of speakers and amplifiers for more than ten years.

QC:All our products comply with international quality standards.

Our Power:The factory area is 5000-10000㎡, with an annual output of 50 million to 100 million US dollars.

Technical Team:The company was founded in 2008, with a team of 50-100 people and a 100% rapid response rate.

We are:

Huiyin Audio is a professional speaker and amplifier supplier located in Guangzhou, China. We are committed to providing mid-to-high-end audio products, including professional audio speakers, car audio speakers, cabinet speakers and amplifiers. Since its establishment in 2008, our joint factory has a complete high-quality supply chain, an excellent management team, and is capable of providing customers with excellent services and high-quality products at affordable prices!

We have:

In recent years, Huiyin Audio Sub-factory has introduced a series of advanced equipment, including automated production lines, high-efficiency magnetizers, impact applicators and temperature testing machines. Huiyin Audio was rated as a high-tech enterprise in 2017.

To adapt to the customer's market, we can customize professional speakers and amplifiers for them according to their needs. ODM and OEM orders are welcome!
