HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party

SKU:
From Trumbosound HYW-1286-003 is a 12-inch low-frequency speaker designed for excellent power handling. It is a daily driver for low-frequency lovers and the best solution for outdoor weddings and parties.The speaker is equipped with high-quality carbon fiber waterproof material, which is light in weight, good in rigidity, and can transmit sound farther, making it the best partner for line array speaker system
0.0 (0 Reviews)
0 Sold
$0.00 $66.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Wholesale:
$64.00
100-1000
Quantity
-
+
0 * $66 = $0
save $0.00
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
1/1
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • HYW-1286-003 12 Inch Neo Woofer 500W RMS Professional Audio Sound System Bass Subwoofer Speakers For Wedding Party
  • Product details
  • Company profile
Parmeter
Model HYW-1286-003
Nominal diameter 12 inch
DC Resistance 6.2Ω
BL Factor 20.4
Effective Moving Mass 70.25
Total Factor(QTS) 0.32
Electrical Factor(QMS) 4.44
Mechanical Factor(QES) 0.34
Compliance(CMS) 0.12
Equivalent Cas Air Load(VAS) 50.9
Resonance Frequency(FS) 52.8
Effettive Pistom Area(SD) 0.05
η(Eta Zero) 2.07

General Specificatons
Nominal Diameter 12 inch
Nominal Impedance
AES power Handling AES 500W
Continuous program power 1000W
Sensitivity 1w/1m 97dB
Frequency Range 50HZ-2KHZ
Voice Coil Diameter 86mm
Winding Material EICCAW
Former Material GBF
Winding Depth 15mm
Magnetic Gap Depth 10mm
surround material Paper cone cloth edge
surround Design W
Magnet Neodymium magnet

Mounting&Shipping Information
Overall Diameter 320mm
Bolt circle Diameter 299-8-Ф9
Baffle Cutout Diameter 280mm
Depth 148mm
Net Weight净 4.90KG
Shipping Weight 6.5KG
Shipping Box(Single) 325×325×150mm

Features
  • Made of high-end waterproof material,it can be use outdoors confidence
  • 1000W continuous high powers,sufficient output energy
  • lightweight,good rigidity,sound can be transmitted farther
  • wide frequency response,can better display the sound from low frequency to high frequency
  • Provides a richer and more realistic auditory experience

Application

  • Outdoor Weddings
  • Mobile performance stage
  • Line array system installation


Our advantage
OEM/ODM:Professional speaker audio manufacturer, focusing on the manufacture and sale of speakers and amplifiers for more than ten years.

QC:All our products comply with international quality standards.

Our Power:The factory area is 5000-10000㎡, with an annual output of 50 million to 100 million US dollars.

Technical Team:The company was founded in 2008, with a team of 50-100 people and a 100% rapid response rate



We are:
Huiyin Audio is a professional speaker and amplifier supplier located in Guangzhou, China. We are committed to providing mid-to-high-end audio products, including professional audio speakers, car audio speakers, cabinet speakers and amplifiers. Since its establishment in 2008, our joint factory has a complete high-quality supply chain, an excellent management team, and is capable of providing customers with excellent services and high-quality products at affordable prices!

We have:
In recent years, Huiyin Audio Sub-factory has introduced a series of advanced equipment, including automated production lines, high-efficiency magnetizers, impact applicators and temperature testing machines. Huiyin Audio was rated as a high-tech enterprise in 2017.

To adapt to the customer's market, we can customize professional speakers and amplifiers for them according to their needs. ODM and OEM orders are welcome!
