From Huiyin Audio's HYW-1575-059 is a 15-inch low-frequency speaker designed for excellent power handling. It is a daily driver for low-frequency lovers and the best solution for outdoor weddings and parties.
| Model | HYW-1575-059 |
| Nominal diameter | 15 inch |
| DC Resistance | 5.8Ω |
| BL Factor | 19.7984 |
| Effective Moving Mass | 91.8254 |
| Total Factor(QTS) | 0.3147 |
| Electrical Factor(QMS) | 5.1274 |
| Mechanical Factor(QES) | 0.3348 |
| Compliance(CMS) | 0.1793 |
| Equivalent Cas Air Load(VAS) | 174.4735 |
| Resonance Frequency(FS) | 34.2192 |
| Effettive Pistom Area(SD) | 0.0835 |
| η(Eta Zero) | 3.0178 |
| Nominal Diameter | 15 inch |
| Nominal Impedance | 8Ω |
| AES power Handling AES | 450W |
| Continuous program power | 900W |
| Sensitivity 1w/1m | 99dB |
| Frequency Range | 40HZ-2.5KHZ |
| Voice Coil Diameter | 75mm |
| Winding Material | Aluminum wire inner and outer layer solid winding |
| Former Material | glassfiber |
| Winding Depth | 13mm |
| Xmax | 15mm |
| surround material | Paper cone cloth edge |
| surround Design | Type W |
| Magnet | Ferrite |
| Overall Diameter | 395mm |
| Bolt circle Diameter | 375-8-Ф6.5 |
| Baffle Cutout Diameter | 360mm |
| Depth | 155mm |
| Net Weight | 7.3KG |
| Shipping Weight | 7.6KG |
| Shipping Box(Single) | 396×396×162mm |
|
