LA3212-V1+TR28B LINE ARRAY SPEAKER FOR PERFOMANCE MOBILE STAGE

SKU:
LA3212-V1 is a three-way four-driver line array speaker system. Line array loudspeakers feature high performance, high power, high directivity, versatility and a very compact cabinet design. Provides 2×12-inch neodymium magnet carbon fiber woofer (75mm voice coil), 4×6.5-inch neodymium magnet carbon fiber mid-range unit (50mm voice coil) and 2×3 neodymium magnet titanium diaphragm tweeter (75mm voice coil), professional performance system. The unique unit design and new materials can effectively enhance the unit's carrying power and are more suitable for working under high-power conditions for a long time, ensuring that the unit achieves high fidelity, broadband, and high fidelity during use.
0.0 (0 Reviews)
0 Sold
$0.00 $12,991.80
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity
-
+
  • LA3212-V1+TR28B LINE ARRAY SPEAKER FOR PERFOMANCE MOBILE STAGE
  • LA3212-V1+TR28B LINE ARRAY SPEAKER FOR PERFOMANCE MOBILE STAGE
  • LA3212-V1+TR28B LINE ARRAY SPEAKER FOR PERFOMANCE MOBILE STAGE
  • LA3212-V1+TR28B LINE ARRAY SPEAKER FOR PERFOMANCE MOBILE STAGE
  • Description
  • Company profile
Specification
LA3212 LA28B D-4130
System type Dual 12-inch three-way four-driver line array speakers Dual 18-inch subwoofers
Frequency response 60Hz -18 kHz (-10dB) 32Hz -250Hz (-10) 20Hz-25Khz ±0.5dB
Sensitivity (1W/1m) HF:107dB MID:100dB LF:98dB 100dB
Nominal impedance (Ω): HF: 8Ω MID: 8Ω LF: 8Ω 4 Ω
Rated power (W) HF: 160W MID: 480W LF1: 400W LF2: 400W 2000W
Bass unit Neodymium magnet, 2×12” carbon fiber woofer/75mm voice coil ferrite, 2×18" woofer/125mm voice coil
Midrange unit Neodymium magnet, 4×6.5" carbon fiber midrange unit/50mm voice coil 133dB /139dB
Tweeter Neodymium magnet, 2×3” titanium diaphragm tweeter/75mm voice coil
Nominal coverage angle (H x V) 100°×10°
Maximum sound pressure level (SPL): LF: 130dB (continuous), 136dB (peak)
Suspension parts three-point suspension, 0°-10° adjustable four-point suspension
Connection socket 2 professional NL8MP eight-core sockets, 2 professional NL4MP four-core sockets 1+1-
Wiring method: LF:1+1 LF:2+2- MID:3+3- HF:4+4-
Dimensions (W×D×H) 1105×521×378 (mm) 1160×920×580 (mm) 88mm×483mm×405mm
Product net weight (kg) 51(kg) 122kg 15kg
8Ω stereo power 4*1300W,
4Ω stereo power 4*2400W,
2Ω stereo power 4*4000W,
8Ω bridge power 2*4400W,
4Ω bridge power 2*5000W
Total harmonic distortion 4Ω/kHz% <0.01%
Signal-to-noise ratio 100dB
Damping coefficient: 500
Input impedance >20KΩ/>10KΩ
Cooling method: stepless speed fan, air flow from front to back
Amplifier protection methods AC soft-start automatic protection at power-on, over-current automatic tracking and current-limiting soft protection,Clip voltage limit, load short circuit, overheating, DC output load loss, shutdown protection, power-on delay pick-up
Power supply specifications AC 150V-260V /50Hz-60Hz

Features
  • LA3212-V1 uses two 75mm titanium film neodymium magnetic compression drivers
  • Four 6.5-inch fabric-edged carbon fiber mid-frequency units
  • 12-inch neodymium magnet carbon fiber woofer
  • Physical location of new tweeter and midrange drivers
  • Horizontal directivity 100°, vertical directivity 10°-90° variable


Application
  • perfomation stage
  • mobile stage
